AKG C114｜Inheriting a Classic, a Large-Diaphragm Multi-Pattern Condenser Microphone Born for Modern Creators
A Professional Studio Microphone with Three Polar Patterns, Ultra-Low Self-Noise, and Wide Dynamic Range
The AKG C114 is a large-diaphragm condenser microphone from AKG, featuring a 26mm edge-terminated dual-diaphragm capsule design derived from the classic C12 and C414, offering three polar patterns: cardioid, omnidirectional, and figure-of-eight. Its optimized transformerless FET circuit achieves an ultra-low self-noise of just 12dB(A) and a maximum SPL of up to 145dB, making it a high-performance microphone designed for studio recording, vocals, instruments, and podcasts.
Compared to microphones in the same price range that only offer a single polar pattern, the C114 provides creators with unparalleled recording flexibility by integrating three classic polar patterns. Whether for solo recording, multi-person interviews, or ambient sound capture, one microphone can easily handle various complex scenarios.
Quick Facts Product Overview
-
Brand: AKG
-
Model: C114
-
Polar Patterns: Cardioid, Omnidirectional, Figure-of-Eight
-
Diaphragm Size: 26mm Edge-Terminated Dual Diaphragm
-
Max SPL: 145dB SPL
-
Equivalent Noise Level: 12dB(A)
-
Applicable Scenarios: Vocal Recording, Instrument Miking, Podcasts, YouTube Content Creation, Live Streaming
AKG C114 Core Technologies and Features
-
Legendary Capsule Design: Equipped with edge-terminated capsule technology derived from the world-renowned AKG C12 and C414, it delivers an exceptionally smooth high-frequency response and beautifully balanced mid-range details, accurately capturing every subtle nuance of sound.
-
Three Polar Patterns: Integrating cardioid, omnidirectional, and figure-of-eight patterns, it offers ultimate recording versatility. Whether recording single vocals, instruments, multi-person interviews, or capturing ambient room sound, it performs perfectly.
-
Ultra-Low Self-Noise Circuit: Utilizes an optimized transformerless FET circuit, achieving an ultra-low equivalent noise level (Self-Noise) of just 12dB(A) and a wide dynamic range, ensuring audio purity and clarity.
-
High SPL Handling: Capable of handling a maximum sound pressure level (Max SPL) of up to 145dB, it can confidently record high-volume sources such as guitar amplifiers and drum kits without distortion or clipping.
-
Simple and Intuitive Operation: User-friendly design ensures extremely simple setup and usage. Just connect to an audio interface with 48V phantom power to start recording, no complex settings required.
-
Sustainable and Eco-Friendly Design: In response to sustainable development, the C114 microphone body is made from 100% recycled PIR (Post-Industrial Recycled) metals and alloys. From packaging to accessories, everything is meticulously designed to minimize environmental impact.
Cardioid Polar Pattern
- The most focused pickup pattern, primarily capturing sound from the front of the microphone while effectively suppressing ambient noise from the sides and rear.
- Most suitable for single vocal recording, instrument solos, podcast hosts, gaming streams, and other scenarios requiring emphasis on a single sound source.
Omnidirectional Polar Pattern
- Picks up sound uniformly from all directions in 360 degrees, capable of fully capturing the natural reverberation and ambient atmosphere of a space.
- Suitable for recording choirs, meetings, round-table interviews, or as a room mic for drum kits to add a sense of space.
Figure-of-Eight Polar Pattern
- Simultaneously picks up sound from the front and rear of the microphone, completely suppressing sound from the left and right sides.
- Ideal for two-person seated interviews, duets, or for stereo recording techniques such as Blumlein and Mid-Side.
Standard Accessories (What's in the Box)
- 1 x C114 Multi-pattern Condenser Microphone
- 1 x H84 Shock mount
Technical Specifications (Tech Specs)
| Capsule Type | 26mm Dual Diaphragm, True Condenser Pressure Gradient |
| Polar Patterns | Cardioid, Omnidirectional, Figure of Eight |
| Frequency Response | 20 Hz – 20 kHz |
| Sensitivity (Cardioid) | 13.5 mV/Pa (-37.4 dBV) |
| Max SPL (0.5% THD) | 145 dB SPL |
| Equivalent Noise Level (A-weighted) | 12 dB(A) |
| Signal-to-Noise Ratio (re 1 Pa) | 82 dB |
| Output Impedance | ≤ 200 ohms |
| Recommended Load Impedance | ≥ 1000 ohms |
| Phantom Power Requirement | 48V +/- 4V (to IEC 61938) |
| Current Consumption | ≤ 5 mA |
| Connector | 3-pin XLR (Male) |
| Dimensions (LxWxH) | 158 x 47 x 35 mm |
| Net Weight | 415 g |
