Antelope Orion 32+ | Gen 4 - 128-track Thunderbolt/USB Professional Audio Interface | Built for Immersive Audio & Mastering-Grade Clocking

Next-Generation High-Channel AD/DA Converter, Providing Unrivaled Connectivity and Pristine Sound Quality for Large Studios

The Antelope Orion 32+ | Gen 4 is a high-end multi-channel audio interface from Antelope Audio, featuring their 4th Generation 64-bit AFC (Acoustically Focused Clocking) technology and AD/DA converters boasting up to 130dB dynamic range. This powerful core, built for modern professional studios, offers extremely high channel count audio transmission capabilities via Thunderbolt 3 and USB ports, and fully supports 24-bit / 192kHz high-resolution audio recording and playback, making it an ideal choice for complex multi-track projects and immersive audio production.

Compared to traditional multi-channel signal chain solutions that require multiple devices to be daisy-chained, the Antelope Orion 32+ Gen 4 achieves high integration in a single 1U rack unit, providing 32-in / 32-out analog signal conversion and massive digital I/O expansion capabilities. Its built-in Dolby Atmos monitoring calibration function and flexible software routing matrix greatly simplify the process of building a modern immersive audio studio, making it stand out among comparable AD/DA converters and the top choice for engineers seeking ultimate sound quality and workflow efficiency.

Quick Facts Product Overview

Brand: Antelope
Model: Orion 32+ | Gen 4
AD/DA Dynamic Range: Up to 130 dB
Thunderbolt 3 I/O: 128 In / 128 Out @ 192kHz
USB 2.0 I/O: 32 In / 32 Out @ 192kHz
Analog I/O: 32 In / 34 Out (incl. Monitor)
Clocking Technology: 4th Generation 64-bit AFC™ (Acoustically Focused Clocking)
Applications: Professional Studio Mixing, Dolby Atmos Immersive Audio Production, Large-Scale Live Performance Recording, Mastering, Multi-track Synthesizer Integration

Who is the Antelope Orion 32+ Gen 4 for?

使用者建議分析(點此展開)

▼

✅ 適合誰購買

Professional producers who need extensive analog I/O to integrate hardware effects, consoles, or multi-track synthesizers.
Immersive audio engineers building or upgrading a Dolby Atmos monitoring system.
Studio owners seeking ultimate sound quality and clocking stability, desiring mastering-grade AD/DA conversion.
Sound engineers who require a high channel count for large band simultaneous recording or multi-track live performance recording.

⚠️ 誰不適合購買

Individual creators or home recording beginners who only need 2-4 input channels for vocal or instrument recording.
Digital music producers whose workflow is entirely in-the-box and have no need for external hardware connections.
Users who require built-in microphone preamplifiers (this model is pure Line I/O).

Antelope Orion 32+ Gen 4 Core Technologies & Features

Mastering-Grade AD/DA Converters: Equipped with newly designed AD/DA conversion chips, offering up to 130dB of dynamic range, capturing the most subtle dynamics and details in sound, bringing unparalleled clarity and depth to your mixes.
4th Generation 64-bit AFC™ Clocking Technology: Utilizing Antelope Audio's industry-renowned 64-bit Acoustically Focused Clocking technology and jitter management algorithms, ensuring perfect clock synchronization between all digital devices, providing stable, precise, and three-dimensional soundstage performance.
Thunderbolt 3 & USB Dual Interface: Thunderbolt 3 enables ultra-low latency transmission of 128 I/O channels, while also being backward compatible with USB 2.0 (providing 32 I/O channels), ensuring excellent compatibility and performance across various Mac and Windows systems.
Immersive Audio Support: Built-in Dolby Atmos speaker calibration and monitoring functions, supporting up to 9.1.6 monitoring configurations. Combined with its high channel count output, it is the ideal core for building a professional immersive audio studio.
Comprehensive Connectivity: In addition to 32-in/32-out analog DB25 connectors, it is also equipped with MADI, ADAT, and S/PDIF digital I/O, offering immense system expansion flexibility for easy integration with large consoles, effects racks, and other digital audio equipment.
Powerful Software Control Panel: The intuitive software control center provides a freely definable signal routing matrix, four 32-channel zero-latency stereo mixers, and preset access functions, making complex signal configuration management simple and efficient.

Software Control Panel & Signal Routing Matrix

Provides a visual signal routing matrix, allowing any input signal to be routed to any output via simple drag-and-drop operations for extremely flexible signal configuration.
Supports preset saving and quick recall functions, allowing dedicated I/O profiles to be created for different work scenarios (e.g., recording, mixing, mastering).
All routing and settings can be controlled via software, eliminating the need for physical patch bays and greatly simplifying studio cable management.

Immersive Audio Integration Features

Natively supports surround sound and immersive audio formats like Dolby Atmos, with support for up to 9.1.6 channel configurations.
Built-in speaker calibration function allows precise adjustment of level and delay for each monitor speaker, ensuring accurate soundstage reproduction.
Compatible with the Antelope MRC multi-channel remote control, providing a tactile monitoring control experience.

Zero-Latency Direct Monitoring Mixer

Features four independent 32-channel stereo mixers, allowing for zero-latency direct monitoring before signals enter the DAW.
Each mixer offers independent control over volume, phase, mute, and other parameters, providing customized monitor mixes for performers.
Can be used for signal summing, mixing multiple tracks internally within the interface before sending them to external hardware or the DAW.

Standard Accessories (What's in the Box)

1 x Orion 32+ | Gen 4 Unit
1 x External Power Supply
1 x Power Cable
1 x USB-C to USB-C Cable
1 x USB-A to USB-C Adapter

Technical Specifications (Tech Specs)

Product Type	Thunderbolt / USB Multi-channel Audio Interface
AD/DA Conversion	Up to 24-bit / 192 kHz
Dynamic Range	Up to 130 dB
Clocking Technology	4th Generation 64-bit Acoustically Focused Clocking (AFC™)
Channels (Thunderbolt 3)	128 In / 128 Out
Channels (USB 2.0)	32 In / 32 Out
Analog Inputs	32 Line Inputs (via 4 x DB25 connectors)
Analog Outputs	32 Line Outputs (via 4 x DB25 connectors)
Monitor Outputs	2 x 6.3 mm TRS Jack
Digital I/O	2 x MADI (Optical), 1 x ADAT (Optical), 1 x S/PDIF (RCA)
Clock I/O	1 x 10M Atomic Clock Input (BNC), 1 x Word Clock Input (BNC), 2 x Word Clock Output (BNC)
Computer Connectivity	1 x Thunderbolt 3 (USB-C), 1 x USB 2.0 (USB-C)
System Requirements	Windows 10 or later / Mac OSX 10.14 or later
Form Factor	19-inch / 1U Standard Rackmount
Dimensions (W x D x H)	483 x 280 x 44 mm
Weight	3.4 kg

Antelope Orion 32+ Gen 4 Pros & Cons Analysis

Pros & Notes (Click to expand)

▼

Pros

Top-tier AD/DA conversion quality with up to 130dB dynamic range, delivering ultimate audio clarity.
Antelope's signature 64-bit AFC clocking technology, ensuring extremely high stability for multi-device synchronization.
Up to 128 channels of Thunderbolt 3 I/O, perfectly meeting the demands of large-scale recording and immersive audio.
Abundant digital ports (MADI, ADAT, S/PDIF), providing powerful system expansion flexibility.

Notes to Know

Does not include built-in microphone preamps; all analog inputs are Line Level and require external preamps.
Initial setup requires an internet connection for online product activation.
The powerful routing matrix feature has a steeper learning curve for beginners.

Antelope Orion 32+ FAQ

Q：Does the Antelope Orion 32+ | Gen 4 have built-in microphone preamps?

▼

A：No. This model is a professional-grade AD/DA converter, with all 32 analog inputs being Line Level, designed for connecting to external consoles, microphone preamps, or hardware effects.

Q：What are the main differences between Orion 32+ | Gen 4 and the previous Gen 3?

▼

A：The main upgrades include an increased AD/DA converter dynamic range of up to 130dB, the adoption of Thunderbolt 3 for higher channel count and bandwidth, and optimized workflow support for immersive audio like Dolby Atmos.

Q：Can I use the Orion 32+ | Gen 4 for Dolby Atmos mixing?

▼

A：Yes. It features built-in Dolby Atmos speaker calibration and monitoring functions, and with its high channel count output, it is an ideal core device for building 7.1.4 or larger immersive audio monitoring systems.

Q：If I'm just doing home recording, do I need to buy the Orion 32+ | Gen 4?

▼

A：Not recommended. This interface is designed for professional studios requiring extensive I/O. Home recording users may consider more streamlined models with built-in preamps, such as the Antelope Zen Go or Zen Q.

Q：Can the Orion 32+ | Gen 4 be connected via USB only?

▼

A：Yes, but with limited functionality. When connected via USB 2.0, it supports up to 32-in/32-out channels. To utilize the full 128-in/128-out performance, a Thunderbolt 3 connection is required.
