UAD Volt 476P

Universal Audio Volt 476P｜4-in/4-out USB-C Audio Interface with Four Built-in 1176 Compressors and Vintage Preamps

Inject Classic Analog Soul into Your Creations: Four-Track Vintage Preamps and 76 Compressors

The Universal Audio Volt 476P is a 4-in/4-out USB-C audio interface, featuring premium 24-bit/192kHz A/D Resolution, four switchable Vintage microphone preamp modes, and built-in analog circuitry derived from the classic 1176 compressor. This interface is designed for musicians, producers, and bands who need to record multiple high-quality audio sources simultaneously, allowing you to easily record more complex, larger-scale productions with legendary studio sound.

Compared to other audio interfaces in the same series or from other brands, the Volt 476P's greatest advantage is that its four input channels are all equipped with complete analog coloration circuitry. This allows you to independently impart warm saturation, like Universal Audio's classic 610 tube preamp, and the punch and dynamic control of the 1176 compressor to each audio source at the initial recording stage, shaping professional sound without relying entirely on post-production plugins.

Quick Facts

Brand: Universal Audio
Model: Volt 476P
A/D Resolution: 24-bit/192kHz
Simultaneous I/O: 4 x 4
Core Features: Built-in Four Vintage Preamps & Four 1176-style Compressors
Use Cases: Band Simultaneous Recording, Multi-person Podcast Interviews, Drum Recording, Live Streaming, Music Production

Who is the Volt 476P suitable for?

使用者建議分析(點此展開)

▼

適合誰購買

Musicians or engineers who need to record multiple microphones simultaneously (e.g., drums, live bands).
Creators running multi-person podcasts or interview shows, seeking independent high-quality audio processing for each participant.
Producers who want to independently add analog coloration and dynamic control to four channels at the recording source.
Recording situations requiring two independent headphone outputs for musicians and engineers to monitor different mixes simultaneously.

誰不適合購買

Users who only need to record one or two audio sources and prioritize extreme portability (consider Volt 176/276).
Mobile recorders who need to be fully USB-powered and prefer not to connect an external power supply.
Producers who seek an absolutely clean, uncolored recording style and are accustomed to performing all post-production within a DAW.

Universal Audio Volt 476P Core Technologies and Features

Premium AD/DA Conversion: Equipped with class-leading 24-bit/192kHz AD/DA converters, ensuring your recordings have excellent clarity, dynamics, and detail.
Four-Track Vintage Microphone Preamp Mode: On all four microphone preamps, activate a one-button analog circuit modeled after UA's classic 610 tube preamp, infusing vocals and instruments with rich, full, classic tube tone.
Four-Track Built-in 76 Compressor: All four input channels feature a true analog FET compressor based on the legendary UREI 1176 hardware, offering three professionally tuned preset modes (VOC, GTR, FAST) to easily add punch and presence to your tracks.
Professional 4-in/4-out I/O: Provides four microphone/instrument Combo inputs, as well as six Line outputs and two independent Headphone Outputs, meeting the needs for band simultaneous recording and multiple monitoring.
Dual Independent Professional Headphone Outputs: Built-in two high-power headphone amplifiers can easily drive high-impedance professional monitoring headphones, with independent volume control, providing a clear and loud monitoring experience.
Zero-Latency Direct Monitoring: Offers direct monitoring functionality, allowing you to hear real-time, zero-latency feedback while recording, ensuring optimal performance.
Comprehensive Connectivity: In addition to rich analog I/O, it is equipped with MIDI I/O ports for connecting your synthesizers and controllers.
Robust Vintage Industrial Design: Features an all-metal chassis with wooden side panels, not only durable but also adding a touch of classic studio style to your desktop.
Bundled Professional Software Suite: The unit comes with a professional recording/mixing software suite, allowing you to start creating, mixing, and mastering right out of the box.

Four-Track Vintage Microphone Preamp Mode

Analog circuitry derived from Universal Audio's classic 610 tube preamp, not digital emulation.
Adds warm, rich harmonics and gentle clipping characteristics to your microphone or instrument signals, giving the sound a classic analog texture.
Each preamp can be independently switched on/off, allowing you to freely choose between a clean modern sound or a characterful vintage tone.

Built-in 76 Compressor

Features a true analog FET compressor based on the legendary UREI 1176 hardware on all four input channels.
Offers three professionally tuned preset modes: VOC (vocals), GTR (guitar), and FAST, providing professional dynamic control with a single click.
Compresses the signal before it enters the digital domain, effectively taming excessive dynamics, increasing audio punch and presence, and preventing digital clipping.

Professional Connectivity and Monitoring

Features 4-in/4-out I/O, including four XLR/TRS combo inputs, allowing simultaneous recording of multiple microphones or instrument sources.
Six 1/4" TRS Line Outputs can connect to multiple pairs of studio monitors or send audio to external hardware effects.
Two independent Headphone Outputs, convenient for engineers and musicians to monitor simultaneously, with independent volume control.
Built-in MIDI I/O ports for easy connection of synthesizers, drum machines, or other MIDI control devices.

Bundled Software

UA Native Software (Perpetual License)

LUNA Recording Software
UA 610 Tube Preamp & EQ Collection
UA 1176 Classic FET Compressor
Teletronix LA-2A Tube Compressor
Century Tube Channel Strip
Vibe Analog Machines Essentials
Pure Plate Reverb
Showtime '64 Tube Amp
PolyMAX Synth

Third-Party Software (Perpetual License)

Ableton Live Lite
Celemony Melodyne Essential
Plugin Alliance Ampeg® SVT-VR Classic Bass Bundle
Softube Marshall® Plexi Classic Amp Bundle
UJAM Virtual Drummer DEEP
UJAM Virtual Bassist DANDY
Spitfire Audio LABS

※ Bundled software is subject to the manufacturer's current shipment and may change without prior notice.

Technical Specifications (Tech Specs)

Computer Connection	USB 2.0
Form Factor	Desktop
Simultaneous I/O	4 x 4
Mic Preamps	4
Phantom Power	Yes
A/D Resolution	24-bit/192kHz
Analog Inputs	4 x XLR/TRS Combo (Mic/Line)
Analog Outputs	6 x 1/4" TRS
Headphone Output	2 x 1/4"
MIDI	In/Out
USB Port	1 x USB-C
Bundled Software	Bundled Professional Recording/Mixing Software Suite
Operating System (Mac)	macOS 10.15 or later, iOS 14 or later
Operating System (PC)	Windows 10 (64-bit) or later
Power Source	Requires included 5V DC power supply (not USB powered)

UAD Volt 476P Pros and Cons

Pros & Notes (Click to expand)

▼

Pros

All four input channels are equipped with Vintage preamps and 1176 compressors, providing consistent high-quality analog tone processing capabilities.
Dual independent Headphone Outputs greatly facilitate monitoring needs for band simultaneous recording or teacher-student instruction.
Premium 24-bit/192kHz AD/DA conversion ensures clear and detailed recording quality.
Robust all-metal construction with vintage wooden side panels, combining durability with professional studio aesthetics.
Provides MIDI I/O for easy integration of synthesizers, drum machines, and other external MIDI devices.

Notes to Know

Due to having four preamps and dual headphone amps, it cannot be USB-powered and requires the included external power supply.
Larger in size compared to 2-in models, which may be a consideration for users with limited desktop space.
The 76 compressor offers three preset modes and does not allow for fine-tuning of parameters like plugins or hardware.

UAD Volt 476P FAQ

Q：What are the core features of the Universal Audio Volt 476P USB-C Audio Interface?

▼

A：It is a 4-in/4-out audio interface, distinguished by its built-in analog Vintage microphone preamps and 1176-style compressors on all four input channels, allowing you to independently add classic warm tone and dynamic control to each source when recording multiple tracks.

Q：What is the difference between Volt 476P and Volt 476?

▼

A：The main difference lies in the number of microphone preamps. The Volt 476P offers four microphone preamps with Vintage mode and compressors; whereas the Volt 476 only has two, with the other two being pure Line-in inputs. Additionally, the 476P provides an extra independent headphone output.

Q：Is the Volt 476P suitable for recording drums?

▼

A：Absolutely. Its four high-quality microphone preamps are sufficient for basic drum miking setups, such as the Glyn Johns four-mic technique, or a kick drum, a snare drum, plus two overheads, making it an excellent choice for small studios recording drums.

Q：Can the two headphone outputs on the Volt 476P play different content?

▼

A：No. These two headphone outputs share the same audio source but allow for independent volume adjustment. They are primarily designed for multiple performers or engineers to monitor the same mix simultaneously.

Q：I am a podcast host and need to record three people simultaneously. Is the Volt 476P worth buying?

▼

A：Absolutely. The Volt 476P provides independent microphone inputs for up to four participants, and each channel can utilize the Vintage preamp and 76 compressor to optimize vocals, significantly enhancing your show's sound quality and production efficiency.
