TOPPING E8x8 Pre | 8-Channel Ultra-Linear Preamp & Dual Headphone Amp Monitoring Interface
The TOPPING E8x8 Pre is a flagship USB Audio Interface designed specifically for professional music production, studio engineering, and multi-track recording needs. This device aggregates TOPPING's years of audio R&D technology, featuring 8 self-developed Ultra-Linear Microphone Preamps and boasting extremely low Equivalent Input Noise (EIN), ensuring the capture of the purest, uncolored sound details at any gain setting. Whether for band synchronous recording, complex drum miking, or professional Podcast production, the E8x8 Pre provides studio-grade superior sound quality.
Beyond its powerful recording input capabilities, the E8x8 Pre features a built-in audiophile-grade NFCA-LE Headphone Amplifier module, providing two independent headphone outputs with an astounding 580mW high power and a noise floor as low as 0.9uVrms. Combined with a zero-latency hardware monitoring system and a dynamic range of up to 132dB, this Professional Studio Equipment allows creators and vocalists to precisely monitor every subtle dynamic change during the recording process. Supporting cross-platform use on Windows, Mac, iOS, and Android, it is the top choice for creators pursuing ultimate sound quality and multi-track expandability.
Core Advantages and Application Scenarios
8 Ultra-Linear Mic Preamps
The E8x8 Pre is equipped with 8 independent microphone preamp channels, adopting TOPPING's self-developed ultra-linear modules. Its Equivalent Input Noise (EIN) is as low as -130.5dBu, meaning that even at high gain, the recording signal remains clean and transparent, free from noise floor interference. Each track supports 48V Phantom Power, perfectly compatible with various condenser and dynamic microphones.
NFCA-LE Flagship Headphone Amplifier Module
To meet professional monitoring needs, the built-in NFCA-LE headphone amplifier circuit achieves an extremely low noise floor of 0.9uVrms and an output impedance of only 1 Ohm. This ensures distortion-free, noise-free driving effects ranging from high-sensitivity in-ear monitors to high-impedance studio headphones. The dual headphone jack design allows the recording engineer and singer to monitor independently at the same time.
Analog Volume Control & Extreme Dynamic Range
The E8x8 Pre uses high-quality analog potentiometers for volume control on both Line Out and Headphone Output, allowing the device to unleash an amazing analog dynamic range. The Line Out dynamic range reaches 127dB, while the headphone output reaches 132dB, making volume adjustment more precise while retaining complete musical dynamics.
LNRD Low Noise Reference Driver Technology
Adopting the exclusive LNRD (Low Noise Reference Driver) module, it provides reference-grade stable power supply for AD/DA chips, effectively filtering out power supply noise interference. This technology maximizes chip performance, achieving excellent data of ADC input dynamic range of 115dB and THD+N lower than 0.0003%, ensuring absolute purity in recording and playback.
Professional Expansion & Clock Synchronization
Features two sets of optical output interfaces (supporting S/PDIF and ADAT protocols), capable of supporting high-resolution audio transmission from 44.1kHz to 96kHz, facilitating connection to external decoding devices. In addition, it is equipped with an independent BNC Word Clock Output, which can serve as the master clock source to synchronize external digital equipment, significantly reducing jitter and improving the sound precision of the overall system.
Detailed Features & Included Software
Technical Specifications (Tech Specs)
- Mic Preamp Channels: 8 Channels
- Equivalent Input Noise (EIN): -130.5dBu (Ultra-Linear Mic Preamps)
- Phantom Power: Supported (All channels 48V Phantom Power)
- Max Sample Rate: 96kHz / 24bit
- Headphone Amp Module: NFCA-LE (TOPPING Self-Developed)
- Headphone Output Power: 580mW x 2 @ 32Ω
- Headphone Output Impedance: 1Ω
- Headphone Output Noise: 0.9uVrms (Low Gain) / 1uVrms (High Specifics vary by measurement condition, ultra-low)
- Line Out Dynamic Range (DNR): 127dB
- Headphone Out Dynamic Range (DNR): 132dB
- ADC Input Dynamic Range: 115dB
- DAC Output Dynamic Range: 115dB
- ADC THD+N: <0.0003%
- Gain Adjustment: Dual-stage gain, high gain mode up to +17dBu
- Digital Output: 2 x Optical (S/PDIF & ADAT), 1 x BNC Word Clock Out
- USB Interface: Dual USB-C Ports
- Compatible Systems: Windows, Mac, iOS, Android
